Amana 40" - Product Dimensions; GUID Furnace Dimensions

PRODUCT DIMENSIONS
5 Rev. 1
FURNACE
MODEL
ABCDE
Minimum
Vent
Diameter
GUID045
GUID070
16-1/2 15 5-1/4 12-5/8 4 4
GUID090 20-1/2 19 7-1/4 14-5/8 4 4
GUID115 24-1/2 23 9-1/4 18-5/8 4 5
GUID DIMENSIONS
All dimensions are in inches.
A Ray theon Co mpany
UPFLOW
FRONT VIEW
A
B
C
3/4
D
BOTTOM
KNOCK-OUT
SUPPLY
SIDE
KNOCK-OUT
31
34 5/8
UPFLOW
RIGHT SIDE VIEW
SUPPLY
28 1/4
31 5/8
37 3/8
23
1 5/8
14
23
BOTTOM
KNOCK-OUT
1 5/8
3/4
20 1/8
28
28 3/4
4 5/8
4 3/4
GAS
SUPPLY
HOLE
ELECTRICAL
HOLE "LOW
VOLTAGE"
ELECTRICAL
HOLE "HIGH
VOLTAGE"
KNOCK-OUT
FOR HORIZONTAL
VENTING
UPFLOW
LEFT SIDE VIEW
3/4
40
1 3/4
4 5/8
SIDE
KNOCK-OUT
