Amana ACVC96 User Manual

4 www.amana-hac.com SS-ACVC96
SS-ACVC96 www.amana-hac.com 5
Airflow Data
ACVC960403BNA
Cooling Speeds
( @ .1" - .8" w.c. ESP)
ACVC960403BNA
Heating Speed
(@ .1" - .5" w.c. ESP; Rise Range: 20 - 50°F)
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Rise
(°F)
A
Minus10% 590 404
A
Minus10% 861 614
41
Minus5% 622 427 Minus5% 909 648 39
Normal 655 449 Normal 957 682 37
Plus5% 688 471 Plus5% 1,005 716 35
Plus10% 721 494 Plus10% 1,053 750 34
B
Minus10% 726 512
B
Minus10% 953 675 37
Minus5% 767 541 Minus5% 1,006 713 35
Normal 807 569 Normal 1,059 750 34
Plus5% 847 597 Plus5% 1,112 788 32
Plus10% 888 626 Plus10% 1,165 825 31
C
Minus10% 898 644
C
Minus10% 1,040 738 34
Minus5% 948 680 Minus5% 1,097 779 32
Normal 998 716 Normal 1,155 820 31
Plus5% 1,048 752 Plus5% 1,213 861 29
Plus10% 1,098 788 Plus10% 1,271 902 28
D
Minus10% 1,086 769
D
Minus10% 1,126 799 32
Minus5% 1,147 811 Minus5% 1,188 844 30
Normal 1,207 854 Normal 1,251 888 28
Plus5% 1,267 897 Plus5% 1,314 932 27
Plus10% 1,328 939 Plus10% 1,376 977 26
ACVC960603BNA
Cooling Speeds
( @ .1" - .8" w.c. ESP)
ACVC960603BNA
Heating Speed
(@ .1" - .5" w.c. ESP; Rise Range: 35 - 65°F)
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Rise
(°F)
A
Minus10% 590 390
A
Minus10% 844 618 63
Minus5% 623 411 Minus5% 891 653 60
Normal 656 433 Normal 938 687 57
Plus5% 689 455 Plus5% 985 721 54
Plus10% 722 476 Plus10% 1,032 756 52
B
Minus10% 711 487
B
Minus10% 855 676 62
Minus5% 751 514 Minus5% 903 713 59
Normal 790 541 Normal 950 751 56
Plus5% 830 568 Plus5% 998 789 53
Plus10% 869 595 Plus10% 1,045 826 51
C
Minus10% 875 617
C
Minus10% 887 733 60
Minus5% 923 652 Minus5% 937 773 57
Normal 972 686 Normal 986 814 54
Plus5% 1,021 720 Plus5% 1,035 855 52
Plus10% 1,069 755 Plus10% 1,085 895 49
D
Minus10% 1,076 725
D
Minus10% 893 787 60
Minus5% 1,135 766 Minus5% 942 830 57
Normal 1,195 806 Normal 992 874 54
Plus5% 1,255 846 Plus5% 1,042 918 51
Plus10% 1,315 887 Plus10% 1,091 961 49
Notes
• Allfurnacesshipashighspeedforcooling.Installermustadjustblowerspeedasneeded.
• Formostjobs,about400CFMpertonwhencoolingisdesirable.
• Installaonistobeadjustedtoobtaintemperaturerisewithintherangespeciedontherangplate.
