ACVC96 Airflow Data (cont.)
ACVC960804CNA
Cooling Speeds
( @ .1" - .8" w.c. ESP)
ACVC960804CNA
Heating Speed
(@ .1" - .5" w.c. ESP; Rise Range: 45 - 75°F)
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Rise
(°F)
A
Minus10% 753 500
A
Minus10% 1,111 800 n/a
Minus5% 795 528 Minus5% 1,172 845 n/a
Normal 837 556 Normal 1,234 889 n/a
Plus5% 879 584 Plus5% 1,296 933 55
Plus10% 921 612 Plus10% 1,357 978 52
B
Minus10% 920 643
B
Minus10% 1,193 850 n/a
Minus5% 971 678 Minus5% 1,259 897 n/a
Normal 1,022 714 Normal 1,325 944 54
Plus5% 1,073 750 Plus5% 1,391 991 51
Plus10% 1,124 785 Plus10% 1,458 1,038 49
C
Minus10% 1,085 754
C
Minus10% 1,298 917 55
Minus5% 1,146 796 Minus5% 1,370 968 52
Normal 1,206 838 Normal 1,442 1,019 49
Plus5% 1,266 880 Plus5% 1,514 1,070 47
Plus10% 1,327 922 Plus10% 1,586 1,121 45
D
Minus10% 1,328 892
D
Minus10% 1,375 961 52
Minus5% 1,401 941 Minus5% 1,452 1,015 49
Normal 1,475 991 Normal 1,528 1,068 47
Plus5% 1,549 1,041 Plus5% 1,604 1,121 n/a
Plus10% 1,623 1,090 Plus10% 1,681 1,175 n/a
ACVC961005CNA
Cooling Speeds
( @ .1" - .8" w.c. ESP)
ACVC961005CNA
Heating Speed
(@ .1" - .5" w.c. ESP; Rise Range: 45 - 75°F)
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Rise
(°F)
A
Minus10% 706 472
A
Minus10% 1,583 1,088 56
Minus5% 745 498 Minus5% 1,671 1,149 53
Normal 784 524 Normal 1,759 1,209 51
Plus5% 823 550 Plus5% 1,847 1,269 48
Plus10% 862 576 Plus10% 1,935 1,330 46
B
Minus10% 970 670
B
Minus10% 1,617 1,124 55
Minus5% 1,024 707 Minus5% 1,707 1,187 52
Normal 1,078 744 Normal 1,797 1,249 49
Plus5% 1,132 781 Plus5% 1,887 1,311 47
Plus10% 1,186 818 Plus10% 1,977 1,374 45
C
Minus10% 1,249 834
C
Minus10% 1,656 1,149 54
Minus5% 1,319 881 Minus5% 1,748 1,213 51
Normal 1,388 927 Normal 1,840 1,277 48
Plus5% 1,457 973 Plus5% 1,932 1,341 46
Plus10% 1,527 1,020 Plus10% 2,024 1,405 44
D
Minus10% 1,589 1,067
D
Minus10% 1,693 1,170 53
Minus5% 1,678 1,126 Minus5% 1,787 1,235 50
Normal 1,766 1,185 Normal 1,881 1,300 47
Plus5% 1,854 1,244 Plus5% 1,975 1,365 45
Plus10% 1,943 1,304 Plus10% 2,069 1,430 n/a
Notes
• Allfurnacesshipashighspeedforcooling.Installermustadjustblowerspeedasneeded.
• Formostjobs,about400CFMpertonwhencoolingisdesirable.
• Installaonistobeadjustedtoobtaintemperaturerisewithintherangespeciedontherangplate.
