ACVC96 Airflow Data (cont.)
ACVC961205DNA
Cooling Speeds
( @ .1" - .8" w.c. ESP)
ACVC961205DNA
Heating Speed
(@ .1" - .5" w.c. ESP; Rise Range: 35 - 65°F)
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Tap Adjust
High-Stage
CFM
Low-Stage
CFM
Rise
(°F)
A
Minus10% 769 486
A
Minus10% 1,570 1,156 n/a
Minus5% 811 513 Minus5% 1,657 1,220 64
Normal 854 540 Normal 1,744 1,284 61
Plus5% 897 567 Plus5% 1,831 1,348 58
Plus10% 939 594 Plus10% 1,918 1,412 56
B
Minus10% 1,011 783
B
Minus10% 1,644 1,179 65
Minus5% 1,067 827 Minus5% 1,736 1,245 61
Normal 1,123 870 Normal 1,827 1,310 58
Plus5% 1,179 914 Plus5% 1,918 1,376 56
Plus10% 1,235 957 Plus10% 2,010 1,441 53
C
Minus10% 1,259 900
C
Minus10% 1,674 1,215 64
Minus5% 1,329 950 Minus5% 1,767 1,283 60
Normal 1,399 1,000 Normal 1,860 1,350 57
Plus5% 1,469 1,050 Plus5% 1,953 1,418 55
Plus10% 1,539 1,100 Plus10% 2,046 1,485 52
D
Minus10% 1,624 1,112
D
Minus10% 1,726 1,249 62
Minus5% 1,714 1,173 Minus5% 1,822 1,319 59
Normal 1,804 1,235 Normal 1,918 1,388 56
Plus5% 1,894 1,297 Plus5% 2,014 1,457 53
Plus10% 1,984 1,359 Plus10% 2,110 1,527 51
Notes
• Allfurnacesshipashighspeedforcooling.Installermustadjustblowerspeedasneeded.
• Formostjobs,about400CFMpertonwhencoolingisdesirable.
• Installaonistobeadjustedtoobtaintemperaturerisewithintherangespeciedontherangplate.
Minimum Filter Sizes
ACVC96
0403BNA
ACVC96
0603BNA
ACVC96
0804CNA
ACVC96
1005CNA
ACVC96
1205DNA
FilterSize(in²)(Qty) (2) 10 x 20 or (1) 16 x 25 (top return)
(1) 14 x 20 (boom) or
(1) 20 x 25 (top return)
Note:Othersizeltersofequalorgreaterdimensionsmaybeused.Filtersmayalsobecentrallylocated.
