Amana AVPEC61D14 User Manual

10
The heating mode temperature rise is dependent upon the system
airflow, the supply voltage, and the heat kit size (kW) selected.
Use data provided in Tables 3,4 and 5 to determine the tempera-
ture rise (°F).
NOTE: For emergency heat, set the dipswitch on PCB. For heating
mode, use the thermostast user menu.
For installations not indicated above the following formula is to
be used:
TR = (kW x 3412) x (Voltage Correction) / (1.08 x CFM)
Where: TR = Temperature Rise
kW = Heater Kit Actual kW
3412 = Btu per kW
VC* = .96 (230 Supply Volts)
= .92 (220 Supply Volts)
= .87 (208 Supply Volts)
1.08 = Constant
CFM = Measured Airflow
*VC (Voltage Correction)
NOTE: The Temperature Rise Tables can also be used to estimate
the air handler airflow delivery. When using these tables for this
purpose set the room thermostat to maximum heat and allow the
system to reach steady state conditions. Insert two thermometers,
one in the return air and one in the supply air. The temperature
rise is the supply air temperature minus the return air temperature.
Using the temperature rise calculated, CFM can be estimated from
the TR formula above. See Specification Sheet and/or Service
Manual for more information.
AVPEC25B14 550 650 700 715 875
AVPEC37C14 850 900 1000 1120 1220 1250
AVPEC59D14 990 1110 1200 1240 1520 1520
AVPEC61D14 1030 1150 1250 1320 1650 1690 1715
Table 6
15 19 20 25
HEATER (kW)
MINIMUM CFM REQUIRED FOR HEATER KITS
Model
356810
3568101519/2025
800 12 19 23 31 37
1000 9 15 19 25 30 44
12008 12152125374962
14007 11131821324253
1600 6 9 12 15 19 28 37 46
1800 5 8 10 14 16 25 33 41
2000 5 7 9 12 15 22 30 31
HEAT KIT NOMINAL Kw
CFM
230/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table 3
3 5 6 8 10 15 19/20 25
8001118223035
1000 9 14 18 24 28 42
12007 12152024354759
14006 10131720304051
1600 6 9 11 15 18 27 35 44
1800 5 8 10 13 16 24 31 39
20004 7 9 1214212835
230/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table
4
CFM
HEAT KIT NOMINAL Kw
3 5 6 8 10 15 19/20 25
8001017212833
1000 8 13 17 22 27 40
12007 11141922334556
14006 10121619293848
1600 5 8 10 14 17 25 33 42
18005 7 9 1215223037
20004 7 8 1113202733
CFM
HEAT KIT NOMINAL Kw
230/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table 5
