21
24 Air Handler Advanced Features Menu
Submenu Item
Electric Heat Size (HTR KW)
Motor HP (1/2, 3/4, or 1 MTR HP)
Heat ON Delay (HT ON) Displays the electric heat indoor blower ON delay.
Heat OFF Delay (HT OFF) Displays the electric heat indoor blower OFF delay.
Submenu Item Indication/User Modifiable Options Comments
Fault 1 (FAULT #1) Most recent modular fault For display only
Fault 2 (FAULT #2) Next most recent modular fault For display only
Fault 3 (FAULT #3) Next most recent modular fault For display only
Fault 4 (FAULT #4) Next most recent modular fault For display only
Fault 5 (FAULT #5) Next most recent modular fault For display only
Fault 6 (FAULT #6) Least recent modular fault For display only
Clear Fault History (CLEAR) NO or YES Selecting “YES” clears the fault history
NOTE:
Consecutively repeated faults are shown a maximum of 3 times
Submenu Item
Model Number (MOD NUM) Displays the modular blower model number
Serial Number (SER NUM) Displays the modular blower serial number (Optional)
Software (SOFTWARE) Displays the application software revision
Submenu Item User Modifiable Options Comments
Heat Airflow Trim (HT TRM) -10% to +10% in 2% increments, default is 0%
Trims the heating airflow
by the selected amount.
Submenu Item
Mode (MODE) Displays the current air handler operating mode
CFM (CFM) Displays the airflow for the current operating mode
Indication (for Display Only; not User Modifiable)
Displays the air handler indoor blower motor horsepower.
CONFIGURATION
Indication (for Display Only; not User Modifiable)
Displays the size in kW of the selected electric heaters.
IDENTIFICATION
Indication (for Display Only; not User Modifiable)
STATUS
DIAGNOSTICS
SET-UP
