ACCESSORIES
5
SS = 2°C (3.6°F) or according
to customer speci cation
Number of turns
from SS to
tight spring
Number of turns
from SS to
loose spring
R22 +7.25 –4.25
R410A +9.5 –2
EXPANSION VALVES
R410A: 0.6°C / turn - 1.1°F / turn
R410A - Max. 75°C (167°F)
Number of turns Number of turns
from SS to from SS to
TIGHT Spring LOOSE Spring
R410A +9.5 -2

-

+
