User advice
32
Mobile fertiliser test kit DB 538.1 04.08
Depending on working width, type of fertiliser and kind of fertilis-
ing (normal- or boundary- or border spreading) take the indications
for
• type of spreading disc,
• mounting height,
• vane position and
• pto shaft rev. speed or spreading disc rev. speed for normal- or
boundary- or border spreading
from the setting chart.
Carry out all settings with greatest care. Deviations from the optimum
setting may change the spread pattern negatively.
We implicitly point out that we do not accept liability for consequential
damage due to spreading errors.
1.5 Affixing of the enclosed self-adhesive foils to the two measurement
funnels
The enclosed self-adhesive foils must be affixed to the two measure-
ment funnels of the mobile test bench as shown.
The numbered foils designate the side of the measurement funnel in
which the collected fertiliser from the respective measurement row
(I to IV) is to be filled.
