Operation with the mobile fertiliser test ki
Mobile fertiliser test kit DB 538.1 04.08
39
After the input of the fertiliser levels I - IV the
optimised vane position for the short and long
vanes is calculated and indicated.
6. Correction of the spreading vane positions
by the calculated spreading vane adjusting
positions.
6.1 Negative value: Swivel backwards the
vanes by the value on the scale.
6.2 Positive value: Swivel forward the
vanes by the value on the scale.
4.3.2 Evaluation with the aid of a pocket computer (PDA)
After having downloaded the software "setting
aid" from the internet, install it on the pocket
computer.
Download under www.amazone.de
1. Start the software on the pocket computer.
2. Enter the number of the read scale lines for
the individual fertiliser levels (I, II, III, IV) in
to the relevant columns (Fig. 7).
3. Actuate key "berechnen" (calculation).
4. The optimised vane settings for the short
and long vanes (kurze und lange Schaufel)
are calculated and indicated.
5. Correction of the spreading vane positions
by the calculated spreading vane adjusting
positions.
5.1 Negative value: Swivel backwards the
vanes by the value on the scale.
5.2 Positive value: Swivel forward the
vanes by the value on the scale.
Fig. 7
The key "Felder löschen" clears the
input and results to carry out a new
evaluation.
