Citan BAG0014.4
11 Faults
11.1 Indication of low seed hopper contents
When the seed level falls below the residual
amount (with properly adjusted seed level sen-
sor) a waning alarm () appears in the
AMATRON
3 / AMALOG
+
with an audible signal.
The residual amount should be sufficiently large
to avoid deviations in the application rate or now
sown areas.
11.2 Failure of AMATRON 3 during operation
Getting the machine in transport position and
immediately see the nearest authorised work-
shop.
1. Stop the tractor engine, apply the parking
brake and remove the ignition key.
2. Remove the guards of the electr.-hydr. con-
trol block.
3. Release the hydraulic valve.
3.1 Fold boom: Pull two valve pins (Fig.
126/1) out of the valves and rotate 45
degrees until they latch.
3.2 Track marker: Unscrew and remove
two valve pins (Fig. 126/2) from the
valves.
4. Advise persons to leave the danger area.
5. Fold in the machine with the aid of the trac-
tor control valves yellow and green.
6.
Get the machine into road transport position
(see Seite 102).
7. Immediately see the nearest authorised
workshop.
126
Only in case of a failure of
AMATRON 3 fold the machine
in emergency mode.
Only actuate the tractor spool
valves within the tractor cab.
Before actuating the tractor
spool valves advise persons to
leave the danger area.
Get the two valve rods (Fig. 126/1) into normal
position.
