Using the field spraye
r
190
Pantera 4504 CP plus BAG0230.2 07.21
12.2.5 211BDiluting the excess residue in the spray liquid tank and spraying out the di-
luted residue remaining at the end of spraying operations
1. Switch off sprayers on the control terminal.
2. Drive the pump with pump operating speed.
3. Dilute the residual quantity with 10 times the amount of flushing
water.
4. Switch of the agitators.
5. Switch on sprayers on the control terminal.
 If possible, first spray out the undiluted spray liquid from the
spray line on an untreated remaining area.
 Spray out the diluted residual quantity on the treated area.
 Keep flushing the diluted residues until air escapes from the
nozzles.
6. Switch off sprayers on the control terminal.
7. Cleaning the field sprayer.
When spreading residue, observe the maximum permissible applica-
tion quantity of the agent on areas already treated.
12.2.6 212BEmptying the spray liquid tank using the pump
1. Couple a suitable emptying hose to the
implement-side emptying connection.
2. Run the pump.
3. TwinTerminal:
Start / stop the quick
emptying
 Confirm that the implement-side connection for
the quick emptying is correctly connected to the
external tank and can draw liquid volumes.
4.
Terminate quick emptying, the valve
is closed
5. Interrupt the pump drive.
6. Uncouple the hose.

