Ambient Weather WS-2902A User Manual

Version 1.6 ©Copyright 2019, Ambient LLC. All Rights Reserved. Page 6
(a)
(b)
Figure 2
5.3.2 Install Wind Cups
Reference Figure 3. (a) push the wind cups on to the shaft. (b) tighten the set screw with a precision
screw driver and make sure the wind cups spin freely.
Note: You may need to back out the set screw first before sliding the cups onto the shaft.
(a)
(b)
Figure 3
5.3.3 Install U-Bolts
Note: Your U-bolts may have come preassembled at the factory.
(a) Insert the U-Bolts into the sensor array mounting bracket and hand tighten the nuts.
(b) Tighten the nuts to fit the size of your mounting pole (between 1” and 2” diameter
(c) Insert the sensor array and U-Bolt assembly onto the mounting pole.
(d) Tighten the U-Bolts around the pole with an adjustable wrench. Make sure the sensor array is
level.

Ambient Weather WS-2902A Specifications

General

Display Type	LCD
Connectivity	Wi-Fi
Update Interval	16 seconds
Humidity Accuracy	±5%
Light Range	0 to 200, 000 Lux
Transmission Frequency	915 MHz
Type	Wireless
Sensors	Temperature, Humidity, Wind Speed, Wind Direction, Rainfall, UV, Solar Radiation
Power Source	AC Adapter (Console), Solar Panel with Battery Backup (Outdoor Sensor)
Compatibility	Ambient Weather Network, Weather Underground
Wireless Range	300 feet (open area)
Outdoor Temperature Range	-40°F to 140°F (-40°C to 60°C)
Temperature Accuracy	± 2 °F
Outdoor Humidity Range	10% to 99%
Rainfall Range	0 to 393.7 inches
Wind Direction	360 degrees
Console Power Source	AC Adapter
Remote Sensor Power	Solar
Wind Speed Accuracy	±1 mph
Data Storage	Cloud Storage
