AMD FirePro V4900 User Manual

4. Install your new AMD FirePro graphics card.
5. Reassemble and connect your computer system.
6. Install the AMD FirePro drivers and configuration software from the ATI
Installation disc.
1.3 Before You Begin Installation
Once you have determined that your system meets the minimum requirements,
please perform the following tasks before installing your AMD FirePro V4900
workstation graphics card.
1.3.1 Recording Serial Numbers
The serial number and 102 part number on the graphics card are required for product
registration. They are located on a sticker on the back of the graphics card and are
shown in boldface and underlined in the illustration below.
Record these numbers in the space provided below and retain for future use.
1. Remove the graphics card from packing.
2. Locate the white label on the back of the graphics card.
3. Record the serial number and 102 part number.
Figure 1–1 Typical Serial Number and 102 Part Number Arrangement
1 Serial number (S/N)
2 102 part number (P/N)
2 Getting Started
AMD FirePro™ V4900 © 2011 Advanced Micro Devices Inc.

AMD FirePro V4900 Specifications

General

GPU	Turks
GPU Architecture	TeraScale 2
Stream Processors	480
Memory Size	1 GB
Memory Type	GDDR5
Memory Interface	128-bit
Memory Bandwidth	64 GB/s
Core Clock	800 MHz
Memory Clock	1000 MHz
DirectX Support	11
Maximum Power Consumption	75 W
Interface	PCIe 2.1 x16
Max Resolution	2560x1600
Form Factor	Single Slot
Outputs	1 x DisplayPort
