AMD Geode LX800


7
Jumper Name Description Page
J1 ATX/AT Mode selecte 3-pin Block p.9
J2 CMOS RAM Clear Function Setting 3-pin Block p.9
J3 CF Card Master/Slave Mode Select 2-pin Block p.10
Connectors
Connector Name Description Page
CN1 Nano-ITX Power Connector 1Phone Jack p.13
12V CN 12V Power Connector 4-pin Block p.13
VGA CN VGA Power Connector 22-pin Block p.13
JUSB1 USB Port Connector 4-pin Connector p.14
LAN1 RJ45 LAN Connector 4-pin Connector p.14
VGA1 VGA Port Connector 15-pin Female p.14
CN4 Line-Out /MIC Audio Connector 2 Phone Jack p.14
PS2 KB PS2 Keyboard Connector 5-PinConnector p.14
CF
Compact Flash Card 50-pin Expansion Socket
p.14
Headers
Header Name Description Page
USB1 USB2.0 Port Headers 9-pin Block p.15
J11 44-Pin Connector 44-pin Block p.15
RESET Reset switch lead 2-pin Block p.15
PWR BTN Power Button Headers 2-pin Block p.15
COM1/COM2
COM3/COM4
Serial Port Headers 9-pin Female p.16
Expansion Sockets
Socket/Slot Name Description Page
DDR
DDR SDRAM Module
Socket
200-pin DDR SODIMM Module
Expansion Socket
p.11
Mini PCI Mini PCI Slot 124-Pin Mini PCI Local Bus Expansion slots p.12
