AMD Geode LX800 - 1-3 Layout Diagram & Jumper Setting


4
Audio
∗ Realtek ALC655 AC97’4-channel Audio Codec integrated
∗ Audio driver and utility included
BIOS
∗ Award 4MB LPC Flash ROM
Multi I/O
∗ PS/2 keyboard Connector
∗ D-Sub 15-pin VGA Conn.x1
∗ USB 2.0 connector x 2, USB2.0 header x1
∗ Serial port header x4
∗ 2-channel Audio connector (Line-out, MIC)
1-3 Layout Diagram & Jumper Setting
MIC-IN
Line-Out
VGA
Gi
g
abit LAN
Power Conn.
USB
