3.2 Display Adapters (Optional Accessories)
The following table lists the options for connecting displays that are not directly
supported by the connection types available on the graphics card.
Adapter Description
DVI-to-VGA adapter
DVI-to-HDMI
If your graphics card includes a DisplayPort or Mini DisplayPort connection, you can
use the following types of DisplayPort-compliant adapters/dongles with your graphics
card:
•
Adapter—Uses DisplayPort signals to transmit audio and video information
between variants of the same connection type (for example, Mini DisplayPort to
standard DisplayPort).
•
Active dongle—Allows connection from a DisplayPort connection to a non-
DisplayPort display using DisplayPort signals.
•
Passive dongle—Allows connection from a DisplayPort connection to a non-
DisplayPort display using non-DisplayPort signals.
Adapters/donglges that are not provided with your graphics cards can also be used
as long as they are compatible with your graphics card and displays. They can be
purchased from AMD's Web site or through your local AMD resellers.
A list of compatible adpaters/dongles can be found at: http://support.amd.com/us/
eyefinity/Pages/eyefinity-dongles.aspx.
3.3 Configuration Options
The AMD Radeon R7 240/R7 250 graphics card provides hardware support for up to
six displays. More than one display can be connected to a DisplayPort connection using
a daisy chain configuration or a hub (via the DisplayPort v1.2 standard).
8 Display Configuration
AMD Radeon™ R7 240/R7 250 Graphics © 2014 Advanced Micro Devices, Inc.
