AMD R7 240 User Manual

10. Reconnect any cables you have disconnected during installation, and then plug
in the computer's power cord.
11. Turn on the monitor, and then the computer.
If you have properly installed the graphics card, the computer should start normally.
Proceed to install the software and drivers for your AMD Radeon R7 240/R7 250
graphics card.
2.3 AMD Drivers and Software
Drivers are small but important programs that enable an operating system to
communicate with a piece of hardware, such as a graphics card.
When you install a new graphics card, you must also install the driver and
configuration software the card requires to function properly.
You also need to install (or reinstall) your AMD Radeon drivers when you have
reinstalled or upgraded your operating system or when you download updated
drivers.
The latest drivers are available from AMD's Web site at http://support.amd.com.
Note: When reinstalling drivers, always uninstall any previous drivers that are on
your system, even if they are for the same graphics card. Always start "fresh."
Hardware and Software Installation 5
© 2014 Advanced Micro Devices, Inc. AMD Radeon™ R7 240/R7 250 Graphics

AMD R7 240 Specifications

General

GPU Architecture	GCN 1.0
GPU	Oland
Process Size	28 nm
Core Clock	730 MHz
Boost Clock	780 MHz
Memory Bus	128-bit
Memory Bandwidth	72 GB/s (GDDR5)
Compute Units	5
Stream Processors	320
Texture Units	20
Render Output Units	8
OpenGL	4.6
OpenCL	1.2
Shader Model	5.1
Power Consumption	30 W
Interface	PCIe 3.0 x8
Max. Resolution	4096x2160
Memory Size	1 GB, 2 GB
Memory Type	DDR3 / GDDR5
Transistors	1, 040 million
DirectX	DirectX 12 (Feature Level 11_1)
