4. Remove any unneeded graphics cards from the computer.
Warning:
Some graphics cards can get hot while operating. Wait approximately five
minutes after turning off the computer before touching the card.
5. Locate the PCIe slots on the motherboard. If necessary, also remove the
corresponding back panel cover.
6. Align the new graphics card in the secondary PCIe slot next to the existing
graphics card and press firmly until the card is fully seated.
Tip: For optimal performance in a dual-GPU AMD CrossFire configuration,
make sure that each AMD Radeon R7 240/R7 250 graphics card is separated by
at least one empty expansion slot.
7. If needed, connect the power supply to the cards.
Tip: The location of power connections may vary between models. They can
be located on either the side or back of the card.
12 AMD CrossFire™ Technology
AMD Radeon™ R7 240/R7 250 Graphics © 2014 Advanced Micro Devices, Inc.

AMD R7 240 Specifications

General

GPU Architecture	GCN 1.0
GPU	Oland
Process Size	28 nm
Core Clock	730 MHz
Boost Clock	780 MHz
Memory Bus	128-bit
Memory Bandwidth	72 GB/s (GDDR5)
Compute Units	5
Stream Processors	320
Texture Units	20
Render Output Units	8
OpenGL	4.6
OpenCL	1.2
Shader Model	5.1
Power Consumption	30 W
Interface	PCIe 3.0 x8
Max. Resolution	4096x2160
Memory Size	1 GB, 2 GB
Memory Type	DDR3 / GDDR5
Transistors	1, 040 million
DirectX	DirectX 12 (Feature Level 11_1)
