AMD R7 240 User Manual

Figure 4–2 AMD CrossFire™ Bridge Interconnect Protection Tag
Figure 4–3 AMD CrossFire™ Installation
1 AMD CrossFire graphics cards
2 Interconnect
9. Fasten the graphics cards securely to the back panel.
14 AMD CrossFire™ Technology
AMD Radeon™ R7 240/R7 250 Graphics © 2014 Advanced Micro Devices, Inc.

AMD R7 240 Specifications

General

GPU Architecture	GCN 1.0
GPU	Oland
Process Size	28 nm
Core Clock	730 MHz
Boost Clock	780 MHz
Memory Bus	128-bit
Memory Bandwidth	72 GB/s (GDDR5)
Compute Units	5
Stream Processors	320
Texture Units	20
Render Output Units	8
OpenGL	4.6
OpenCL	1.2
Shader Model	5.1
Power Consumption	30 W
Interface	PCIe 3.0 x8
Max. Resolution	4096x2160
Memory Size	1 GB, 2 GB
Memory Type	DDR3 / GDDR5
Transistors	1, 040 million
DirectX	DirectX 12 (Feature Level 11_1)
