Bank MIO # Device Signal I/O Notes
18 PMC_MIO18_USB_CLKOUTO
19 PMC_MIO19_USB_DAT4 I/O
20 PMC_MIO20_USB_DAT5 I/O
21 PMC_MIO21_USB_DAT6 I/O
22 PMC_MIO22_USB_DAT7 I/O
23 PMC_MIO23_USB_DIR I/O
24 PMC_MIO24_USB_STP O
25 PMC_MIO25_USB_NXT I/O
501 26 SD PMC_MIO26_SD_CLK O
27 PMC_MIO27_SD_DIR1 O
28 PMC_MIO28_SD_DET I
29 PMC_MIO29_SD_CMD I/O
30 PMC_MIO30_SD_DAT0 I/O
31 PMC_MIO31_SD_DAT1 I/O
32 PMC_MIO32_SD_DAT2 I/O
33 PMC_MIO33_SD_DAT3 I/O
34 PMC_MIO34_SD_SEL I/O
35 PMC_MIO35_SD_DIR_CMDO
36 PMC_MIO36_SD_DIR0 O
37 Factory/CANFD0
See CAN
Interface
PMC_MIO37_COMBINED I/O Selectable J406,
Factory/CANFD0_INH_B
38 CANFD0 PMC_MIO38_CAN0_nSTBO Standby mode
control input
