Bank MIO # Device Signal I/O Notes
7 LPD_MIO7_GEM_RX_D0 I/O
8 LPD_MIO8_GEM_RX_D1 I/O
9 LPD_MIO9_GEM_RX_D2 I/O
10 LPD_MIO10_GEM_RX_D3 I/O
11 LPD_MIO11_GEM_RX_CTLI/O
12 Regulator
Enable
GPIO
LPD_MIO12_VCC_PSFP_ENO See Table 1
13 Regulator
Enable
GPIO
LPD_MIO13_VCC_SOC_ENO See Table 1
14 CANFD0
See CAN
Interface
LPD_MIO14_CANFD0_RX I
15 LPD_MIO15_CANFD0_TX O
16 CANFD1
See CAN
Interface
LPD_MIO16_CANFD1_TX O
17 LPD_MIO17_CANFD1_RX I
18 PCIe PCIE_PERST_B I
19 PCIE_PERST_B I
20 Regulator
Enable
GPIO
LPD_MIO20_VCC_PL_EN O See Table 1
21 Fan MIO21_FAN_PWM_VERSALO Versal device fan
PWM
22 MIO22_FAN_TACH_VERSALI Versal device fan
tach
23 Regulator
Enable
LPD_MIO23_VADJ_FMC_ENO VADJ_FMC enable
