IMPORTANT! The following gure is for visual reference only and might not reect the current revision of
the board.
IMPORTANT! There could be mulple revisions of this board. The specic details concerning the
dierences between revisions are not captured in this document. This document is not intended to be a
reference design guide and the informaon herein should not be used as such. Always refer to the
schemac, layout, and XDC les of the specic VPK180 version of interest for such details.
Chapter 2: Board Setup and Configuration
