AMD XILINX VPK180 - Navigating Content by Design Process; Additional Resources

Table 1: Models of VPK180 Evaluation Boards
Kit Description
EK-VPK180-G Xilinx Versal ACAP VPK180 evaluation kit
EK-VPK180-G-J Xilinx Versal ACAP VPK180 evaluation kit, Japan specific
Versal ACAP Kit Numbering
The Versal ACAP kit numbering is illustrated in the following gure.
Figure 1: Kit Numbering
EK - VP
Kit
Type
Options
EK –Evaluation Kit
CK –Characterization Kit
K 180 - G - J
ROHS
Indicator
Regional
Identifier
Silicon indicator
K = kit
Ensures there is no
confusion with silicon P/Ns
Family and series
(e.g., Versal ACAP
and Core)
Examples
VPK120
VCK190
Options
G –ROHS
Compliant
Options
J –Japan
OEM –OEM kit
Product Number
X26520-111822
Navigating Content by Design Process
Xilinx
®
documentaon is organized around a set of standard design processes to help you nd
relevant content for your current development task. All Versal
®
ACAP design process Design
Hubs and the Design Flow Assistant materials can be found on the Xilinx.com website. This
document covers the following design processes:
• Board System Design: Designing a PCB through schemacs and board layout. Also involves
power, thermal, and signal integrity consideraons. For more informaon, see Versal ACAP
Design Process Documentaon Board System Design.
Additional Resources
See Appendix D: Addional Resources and Legal Noces for references to documents, les, and
resources relevant to the VPK180 evaluaon board.
