Default Jumper and Switch Settings
The following gure shows the VPK180 board jumper header and switch locaons. Each
numbered component shown in the gure is keyed to the applicable table in this secon. Both
tables reference the respecve schemac page numbers.
Figure 4: Board Jumper Header and Switch Locations
1
2 3
4
5
8
7
9
10
11
12
13
15
17
18
20
16
14
21
6
19
X27291-101322
