Table 2: Board Component Locations (cont'd)
Callout
No.
Ref. Des. Feature Notes
Schematic
Page
38 U248 LPDDR4 CLK1, 200 MHz, 3.3V
LVDS, 0x60
Skyworks/Silicon Labs 570BAB000299DGR
Osc. XO 10-810 MHz
Bottom of board
3
39 U3 LPDDR4 CLK2, 200 MHz, 3.3V
LVDS, 0x60
Skyworks/Silicon Labs 570BAB000299DGR
Osc. XO 10-810 MHz
Bottom of board
4
40 U4 LPDDR4 CLK3, 200 MHz, 3.3V
LVDS, 0x60
Skyworks/Silicon Labs 570BAB000299DGR
Osc. XO 10-810 MHz
Bottom of board
5
41 J373, J374, J375,
J376, J393, J394,
J395, J396
ACAP GTM female vertical 12.4
GHz SMT screw connector
Rosenberger 32K10K-400L5
Conn. rcpt. SMA vert. 50R 12.4 GHz
11
42 DS1 Done LED (Active-High-Z and
pulled High)
Lumex SML-LX0603GW-TR
LED green
22
43 DS2 Error out LED (Active-High-Z
and pulled High)
Lumex SML-LX0603IW-TR
LED red
22
44 DS3, DS4, DS5,
DS6
User LEDS Lumex SML-LX0603GW-TR
LED green
65
45 U251, U252,
U257
IEEE-1588 eCPRI input clock
multiplexer
Renesas 8P34S1204NLGI8IC buffer Clk 2 to 4
1.8-2.5V 10 mA 1.5 GHz LVDS
113
46 U219 IEEE-1588 eCPRI CLK, various,
3.3V, 0x58
IDT 8A34001E-000AJG8
IC synch. man. unit 8-Ch 24 LVCMOS
Bottom of board
111,112
47 J328, J329, J338 IEEE-1588 eCPRI 8A34001 CLK
in SMA
Rosenberger 32K10K-400L5
Conn. rcpt. SMA vert. 50R 12.4 GHz
111
48 J330, J331, J339 IEEE-1588 eCPRI 8A34001 CLK
out SMA
Rosenberger 32K10K-400L5
Conn. rcpt. SMA vert. 50R 12.4 GHz
111
49 U125 XCZU4EG system controller Xilinx
®
XCZU4EG-2SFVC784E
FPGA MPSoC Zynq UltraScale+
93-101
50 U319 SYSCTLR clocks 33.33 MHz and
26 MHz USB and 156.25 MHz
HSDP REFCLK 0x6A
Skyworks/Silicon Labs Si5332FD10259-GM1
Low jitter clock generator with 6 outputs
108
51 U132 System controller LPDDR4 16
GBIT comp. memory
Micron MT53D512M32D2DS-046 WT:D
IC SDRAM LPDDR4 16 Gb 512Mx32 2133
MHz
105
52 J349 System controller SGMII
Ethernet, RJ45 w/magnetics
Halo HFJ11-1G01E-L12RL
RJ-45 Gigabit connector
103
53 J7, U19 System controller USB 3.0 type-
B connector , USB ULPI
transceiver
Wurth 692622030100, USB 3.0 type-B
Microchip USB3320C USB 2.0 Xcvr Bottom of
board
107
54 DS34 System controller done LED
(active-High)
Lumex SML-LX0603GW-TR
LED green
97
55 J362 OSFP 112G connector TE connectivity 2344064-4
OSFP 112G connector and cage
60
Notes:
1. The VPK180 evaluation board includes a heatsink with a thermal resistance of 0.38°C/W.
