Table 2: Board Component Locations (cont'd)
Callout
No.
Ref. Des. Feature Notes
Schematic
Page
16 J307 GEM0 SGMII Ethernet PHY,
0x01, RJ45 w/mag
Halo HFJ11-1G01E-L12RL
RJ-45 Gigabit connector
52
17 J51 FMCP1 Samtec ASP-184329-01
560 pos. connector 14x40 1.27 mm
46-50
18 Various ACAP power management
system (VCCINT, VCC_SOC)
Infineon regulators 67-73,75
19 U160, U293 VCC_PMC/PSFP/VCCO_MIO/
VCCAUX/VCC1V5/UTIL_3V3
regulator
Infineon IRPS5401MTRPBF
IC PMU 5-Ch step-down DC/DC
76,77
20 U167, U294 VCCRAM_VCCINT/
LPDMGTYAVCC/MGTVCCAUX/
MGTAVCC regulator
Infineon IRPS5401MTRPBF
IC PMU 5-Ch step-down DC/DC
78,79
21 U175, U296 VCCAUX/UTIL_2V5/
VCC_PSLP_CPM5/
LPMGTYVCCAUX regulator
Infineon IRPS5401MTRPBF
IC PMU 5-Ch step-down DC/DC
80,81
22 U295 UTIL_1V8/VCCAUX_PMC/
LPDMGTYAVTT regulator
Infineon IRPS5401MTRPBF
IC PMU 5-Ch step-down DC/DC
82
23 U259 LPDMGTYAVTT regulator Infineon IR38060MTRPBF
IC REG BUCK ADJ 6A
85
24 U185 VADJ_FMC regulator Infineon IR38164MTRPBFAUMA1
IC V. reg. step-down DC/DC sync
86
25 U187 VCC1V1_LP4 regulator Infineon IR38164MTRPBFAUMA1
IC V. reg. step-down DC/DC sync
87
26 U189 MGTYAVTT regulator Infineon IR38164MTRPBFAUMA1
IC V. reg. step-down DC/DC sync
88
28 U191 UTIL_5V0 regulator Infineon IR3889MTRPBFAUMA1
IC V. reg. step-down DC/DC sync
89
29 J325 PMBus 3-pin header Sullins PBC03SAAN
Conn. hdr. vert. 3 pos. 1x3 2.54 mm
55
30 Various Power good LEDs (see Power
and Status LEDs for more
details)
Various; see the Bill of Materials 91
31 J16 Power connector, 2x3, for AC-
DC power adapter
Molex 0039301060
Conn. ddr. RA 6 pos. 2x3 4.2 mm
66
32 JP1, JP2, JP3, JP4 Power connector, 2x4, for ATX
PCIe power
Astron 6652208-T0003T-H
Conn. hdr. male RA 8 pos. 2x4 4.2 mm
66
33 J233 Fan header (keyed 4-pin) Molex 0470533000
Keyed fan header 4 pos. 0.100" vert.
66
34 U298, U299 MGT clock generators Renesas RC21008A065GND#BB0 61,62
35 J370, J371 RC21008A_GTCLK1/2 header Molex 0878321820 61,62
36 U11, U12 ACAP U1 QSPI Micron MT25QU01GBBB8E12-0SIT
IC flash NOR SPI 1 Gb
45
37 U32 ACAP U1 REF CLK, 33.33 MHz,
1.8V CMOS, 0x5D
Skyworks/Silicon Labs 570JAC000900DGR
Osc. XO 10-280 MHz
Bottom of board
54
