Board Component Descriptions
The following table idenes the components and references the respecve schemac
(038-05088-01) page numbers.
CAUTION! Do NOT plug a PC ATX power supply 6-pin connector into the VPK180 board power
connector J16. The ATX 6-pin connector has a dierent pinout than J16. Connecng an ATX 6-pin
connector into J16 damages the VPK180 board and voids the board warranty.
Table 2: Board Component Locations
Callout
No.
Ref. Des. Feature Notes
Schematic
Page
1 U1 Versal
®
ACAP XCVP1802-2MSELSVC4072
The heatsink is not shown in Figure 3
1
3-23
2 U25, U26 LPDDR4 16 GBIT comp.
memory (B700-B702 IF)
Micron MT53D512M32D2DS-046
IC SDRAM LPDDR4 512Mx32 2133 MHz
3,39,40
3 U150, U151 LPDDR4 16 GBIT comp.
memory (B703-B705 IF)
Micron MT53D512M32D2DS-046
IC SDRAM LPDDR4 512Mx32 2133 MHz
4,42,41
4 U246, U247 LPDDR4 16 GBIT comp.
memory (B706-B708 IF)
Micron MT53D512M32D2DS-046
IC SDRAM LPDDR4 512Mx32 2133 MHz
5,43,44
5 J11 SYSMON header Sullins PBC06DAAN
Conn. hdr. vert. 12 pos. 2x6 2.54 mm pitch
20
6 J36 ACAP JTAG 2 mm 2x7 flat-cable
connector
Molex 0878321420
Conn. hdr. male vert. 14 pos 2x7 2 mm
35
7 J332 Mictor-38 Arm
®
trace
connector
TE connectivity AMP connectors
2-5767004-2
Conn. hdr. MICTOR 38 pos. 2x19 0.635 mm
38
8 J310 8A34001 I2C 2 mm 2x9 flat-
cable connector
Molex 0878321820
Conn. hdr. male vert. 18 pos. 2x9 2 mm
111
9 J369, U20 USB-UART bridge, USB Type-C
connector (USB2.0)
Amphenol 12401598E4#2A
FTDI FT4232HL-REEL
36
10 J308, U99 USB 2.0 type-A connector, USB
ULPI transceiver
Wurth 629104190121, USB 2.0 type-A
Microchip USB3320C USB 2.0 Xcvr
53
11 J302, U104 SD card socket, Versal ACAP SD
3.0 level translator circuit
Molex 5025700893
Micro SD card cage
51
12 U33, U35 I2C bus switches Texas Instruments TCA9548APWR
IC switch bus 1-In 8-Outs I2C 400 kHz
Bottom of board
55,56
13 U233 I2C bus expander Texas Instruments TCA6416APWR
IC exp. GPIO 16-bit I2C 400 kHz
Bottom of board
55
14 J1, J2, J354,
J355, J358, J359
QSFP-DD 112G connector Molex 2147334000
QSFP-DD 112G connector and cage
57-59
15 J350, J352, J385,
J387
SFP-DD 56G connector Molex 2047301000
SFP-DD 56G connector and cage
63,64
