Jumpers
The following table lists the default jumper sengs.
Table 3: Default Jumper Settings
Callout
Number
Ref. Des. Function Default
Schematic
Page
1 J11 SYSMON VREFP SEL
1-2: External VREF
2-3: Disable external VREF
1-2 20
2 J26 POR_B supervisor SENSE input
1-2: VCCO_MIO ramp-up sense (1.8V)
2-3: VCCAUX_PMC ramp-up sense (1.5V)
1-2 23
3 J326 POR_B enable header
1-2: SYSCTLR can drive POR_B
3-4: PC4 can drive POR_B
5-6: FTDI can drive POR_B
Open: POR_B source not connected
1-2, 3-4 jumpered
5-6 open
23
4 J34 VCC Fuse programming enable
1-2: Fuse programming enabled
2-3: Fuse programming disabled
2-3 25
4 J37 JTAG source enable
1-2: JTAG sources disabled
2-3: JTAG sources enabled
2-3 35
5 J300 USB shield GND
1-2: USB connector DC grounded
2-3: USB connector no DC grounded
1-2 53
6 J301 SD REF
1-2: 3.3V REF
2-3: GND REF
1-2 51
7 J203 SYSCTLR POR_B supervisor enable
1-2: SYSCTLR POR_B supervisor enabled
Open: SYSCTLR POR_B supervisor disabled
1-2 97
8 J347 Fan type
1-2: System controller PWM
2-3: Versal ACAP MIO PWM
2-3 66
8 J348 TACH type
1-2: System controller TACH
2-3: Versal ACAP MIO TACH
2-3 66
9 J345 LPDMGTYAVTT enable select
Installed: Versal ACAP control
Not installed: enabled by UTIL_5V0_PGOOD
Open 90
10 J12 SYSMON VREF selection
Default VREF = 1.024V
1-2 20
