Switches
The following table lists the default switch sengs.
Table 4: Default Switch Settings
Callout
Number
Ref. Des. Function Default
Schematic
Page
11 SW1 U1 mode 4-pole DIP switch
Switch OFF = 1 = high; ON = 0 = low
Mode = SW1[1:4] = Mode[0:3]
SD = ON,OFF,OFF,OFF = 0111
QSPI32 = ON,OFF,ON,ON = 0100
JTAG = ON,ON,ON,ON = 0000
ON, ON, ON, ON
22
12 SW2 VPK180 power-on reset (POR_B) Open 23
13 SW3 SYSCTLR JTAG source selection
Switch OFF = 1 = high; ON = 0 = low
SYSCTLR JTAG SOURCE SEL = SW3[1:2] = SEL[0:1]
PL JTAG = ON,ON = 00
FTDI JTAG = OFF,ON = 10
Trace Mictor38 JTAG = ON,OFF = 01
OFF, ON
35
14 SW4, SW5 User pushbutton inputs
Note: Pushbutton switch default = open = logic low
(not pressed).
Open 65
15 SW6 User GPIO DIP
Switch OFF = 0 = low; ON = 1 = high
OFF, OFF, OFF, OFF 65
16 SW11 SYSCTLR mode 4-pole DIP switch
Switch OFF = 1 = high; ON = 0 = low
Mode = SW1[1:4] = Mode[0:3]
QSPI32 = ON,OFF,ON,ON = 0100
eMMC = ON,OFF,OFF,ON = 0110
JTAG = ON,ON,ON,ON = 0000
ON, OFF, ON, ON
97
17 SW12 System controller power-on reset (SYSCTL_POR_B) Open 97
18 SW13 Main power OFF 66
19 SW14 User USB reset Open 53
20 SW15 User GEM reset Open 52
21 SW16 System controller FWUEN pushbutton
(SYSCTLR_MIO12_FWUEN_C2M_B)
See BEAM wiki for more information
Open 96
