The I2C0 bus topology gure and I2C0 port expander TCA6416A U233 address 0x20
connecons table in PMC MIO[46:47] I2C0 Bus document the I2C0 bus access path to the
Inneon PMBus controllers and INA226 power monitor op amps. Refer to schemac for
connecvity details. This can be accessed through the VPK180 Evaluaon Board website. These
power system components are also accessible to the ZU4 U125 system controller (bank 501) and
the ACAP U1 (bank 501).
