Specifications 7
SHD-66/46P Manual
• Model: Champion R30D
• Weight: 425 lbs. (dry)
• Cylinders: Four Cylinder(Two Stage)
• Delivery: 46 CFM @ 175 PSI
• Maximum Working Pressure: 175 PSI
• Maximum Compressor Speed: 1000 RPM
• Dimensions: (w/o reservoir) 33.5”L x 23.5”W x 25.5”H
(w/ reservoir) 48.5”L x 23.5”W x 25.5”H
• Electrical: 12 VDC
• Crankcase Oil Capacity: 4 Quart
• Oil Reservoir Capacity: 16 Gallons
• 18 GPM Hydraulic System • 2200 PSI System Pressure
• 2700 PSI Pressure Relief Setting • 12 VDC Solenoid Control Valve
• All Steel Plumbing W/ JIC Fittings • 165 Sq. In., 300 BTU Cooler
• 861 CFM, 12 Volt Cooler Fan • 6061 Aluminum Manifold
• Direct Drive Coupling • Air Pressure Control Valve
Drive System Description
Compressor System Description
General Information
• Cast Iron Crankcase Casting • Tapered Roller Main Bearings
• Gasket-free Integrated Cylinder/Head • Heavy Ductile Iron Crankshaft
• Precision Balanced Flywheel • Pressure Relief Valves in interstage
and discharge
• Large Diameter Finned Inner Cooling Tubing • Splash Lubricated System
• Positive Acting Centrifugal Head Unloaders • Preset Pilot Control Valve
Chapter 2: Specifications
