V230
COMPRESSOR SPECIFICATIONS
Compressor System Description
• Cast Iron Crankcase Casting
• Cast Aluminum Cylinder Heads
• High Temperature Precision Pistons
• Stainless Steel Reed Valves
• Pulsation Manifold
• Heavy Ductile Iron Crankshaft
• Micro-honed Connecting Rods
• Tapered Roller Bearings
• Splash Lubricated System
• Heavy Duty Journal Bushings
General Information
• Model: V230
• Weight: 87 lbs.
• Delivery: 28 CFM @ 100 PSI
• Maximum Working Pressure: 155 PSI
• Oil Capacity: 1 Quart
• Cylinders Four Cylinder (Single Stage)
• Pressure switch presets Engage – 115 PSI
Disengage – 150 PSI
GENERAL OPERATIONS
Each compressor is bench tested under load at the factory to ensure proper break-in and
operation. While it is not necessary to follow any break-in procedure, the following
checks should be made before putting the unit into service and periodically during use.
Before Start-Up
Check the oil level in the compressor with the dipstick on the unit. If oil is needed, use
Stellar synthetic compressor oil (P/N C0087) or equivalent synthetic 10W-20.
Check the air intake filters on each head to make certain that they are clean and
unobstructed. Dirty air filters are a possible cause of reduced air output.
