10
CYLINDER GROUP
ITEM PART DESCRIPTION QTY. ITEM PART DESCRIPTION QTY.
1 C0047 CYLINDER GASKET 2 7 6036 RING OIL V360 2
2 22628 CONNECTING ROD V230 2 8 6037 RING CPRSN V360 SQ GROOVE 2
3 22691 ROLL PIN 0.25X1.50 2 9 C0065 RING CPRSN 4
4 C2018 PISTON 2.63 OD 2 10 C0045 CYLINDER 1
5 C1569 PISTON PIN 2 11 0522 WASHER 0.31 LOCK 6
6 C6273 SNAP RING PISTON PIN 4 12 C0922 CAP SCR 0.31-18X1.00 HHGR5 6
To Next Page
