Medallion Dual Fuel Ranges
Use & Care Manual
INSTALLATION INSTRUCTIONS
GENERAL
Theseinstructionsareprovidedtoassistthequaliedinstaller.Itistheowner’sresponsibilitytoensurethatallgoverningcodesand
ordinances are observed during the planning and installation of this appliance.
OVERALL RANGE DIMENSIONS
CAUTION
!
Failure to follow these installation guidelines will affect warranty coverage.
IMPORTANT
30 -1/2"
29-7/8"
30 -1/2"
35-7/8"
47-7/8"
30 -1/2"
37"
59-7/8"
30 -1/2"
46 -1/2"
37"
37"
37"
