Medallion Dual Fuel Ranges
Use & Care Manual
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com
11
Oven Racks: Each oven is supplied with two heavy chrome-
plated adjustable oven racks.
Rack Supports: On each side of the oven, heavy chrome-plated
racksupportsallowvepositions,numberedfromthebottom
up.
Oven Control Knob: The oven control knob is used to set the
Baking temperature or to select the Broil function. During baking,
the convection fan may be activated.
Bake Burner: The Bake burner is located in the center of the
oven,belowtheoorandisactivatedbytheOvenControlKnob.
Magma Grill Infrared Broil Burner: Positioned in the oven ceiling,
a highly insulated ribbon element lights up to a temperature of
1,850ºF – creating searing heat similar to the glowing coals of a
woodre.
Inconel
®
Screen Infrared Broil Burner: This broil burner is also
positioned in the oven ceiling, burning gas heats the Inconel
Screen to 1,850ºF, perfect for browning and crisping.
Broil Burner Igniter: The igniter glows a very hot, bright red-
orange color, reaching proper ignition temperature to light the
Inconel Screen Infrared Broil Burner.
Burner On Indicator Light: Whenever an oven burner is
activated(eitherBakeorBroil),theburneronindicatorwillglow.
It is normal for the indicator light to cycle off and on during
baking or broiling – showing that the requested temperature has
been achieved – or that more heat is required.
Door Gasket: The door gasket is made from high temperature
materials and creates a seal between the hot oven and the cool
kitchen.
Convection Fan and Switch: Operated by the front panel
switch, the convection fan circulates oven air, removing the
“thermal boundary layer” on items being baked – and in doing
so – speeding up heat transfer and cook time by as much as 25%.
Convection is active only during baking.
Oven Light and Switch: A single lamp is provided in the oven
to illuminate baked and broiled food items, as well as shed some
light on the wall to help during clean-up – activated by the front
panel switch.
MODEL AND PARTS IDENTIFICATION
Oven Racks 2 2 2 2 4 4 4 4 4 4 4 4
Sealed Burners 4 4 6 4 6 4 6 4 6 6 6 6
Center Plate 1 0 0 0 0 0 0 0 0 0 0 0
Grates 3 2 3 3 3 4 4 2 4 4 3 5
Control Knobs 4 5 6 5 7 6 8 6 7 8 8 8
Griddle 0 1 0 0 1 0 1 1 0 1 1 0
Backyard Grill 0 0 0 1 0 2 1 0 1 1 0 2
Regis. Card 1 1 1 1 1 1 1 1 1 1 1 1
U&C Manual 1 1 1 1 1 1 1 1 1 1 1 1
ARR-304DF
ARR-364GRDF
ARR-366DF
ARR-364GDDF
ARR-486GDDF ARR-4842GDDF ARR-486GDGRDF
ARR-484X2GRDF
ARR-486GRDF
DESCRIPTION
MEDALLION SERIES - DUAL FUEL RANGES
ARR-606GDGRDF
ARR-60X2GRDF ARR-6062GDDF
