Ameristar 4TXK1609A1 - Page 36

30 9/16
21 1/4
12 3/5
82
11 1/4
20
10 1/8
Unit: inch
35
13 3/8
27 9/16
15 5/8
38
14 5/16
22
9K-12K Outdoor Units
18K-24K Outdoor Units
Outdoor Unit Dimensions
The dimensions in these drawings
are rounded according to standard
measurement.
The dimensions in these drawings
are rounded according to standard
measurement.
36
16 Series Mini-Split
