Ametek 3330 - Specifications

P-2 PREFACE
Specifications
Pressure Range: 100 PSIG
Temperature Range: 32°F – 160°F
Flowrate: 1-5 gpm
Viscosity Range: 0-160 cP
Input Voltage: 12VDC
Power: 6 A @ 12VDC
Dimensions: 13.5” x 17” x 20”
Net Weight: 56 lbs. (36 kg)
Operating Speed: 300 RPM (511 sec
-1
)
Connections: ½” NPT threads
Signal: 4-20 mA @ 600 ohms max
