Ametek LAND R1500T User Manual

Landcal Blackbody Source
Type R1500T
User Guide
Page 6
Fig. 2 Wiring diagram for the LANDCAL Blackbody type R1500T CA970249
4.4 Wiring diagram
GR/Y
L N E
TC
2 3
5
9 Pin ‘D’ connector
RS 232
SSR
ELEMENT(S)
Mains filter
+ -
L N
R
R
+
-
+
-
Thermocouple
HEAT
PI G
BU
R
BU
Instrument
switch
Supply
light
F2
F2
F1 F1
F3 F3
R Red SSR Solid State Relay
PI Pink
BU Blue TC Temperature Controller
GR/Y Green & Yellow
GR Grey F Fuses
