Ametek Powervar Security Plus II - Required Circuit Protection Ratings

16
A01-00150 Rev B
4.3 Circuit Protection Requirements (Hardwired units only)
All AMETEK Powervar Hardwired Security Plus II UPS system’s mains
INPUT must be protected by proper sized branch circuit breakers in the
building installation. The recommended branch circuit ratings at full rated
load are listed below:
ABCDEF2002-11 35 AMP
ABCDEF3002-11
45 AMP
208V
240V
ABCDEF2002-22 20 AMP 15 AMP
ABCDEF3002-22
25 AMP
20 AMP
ABCDEF4002-22 35 AMP 25 AMP
ABCDEF5202-22
40 AMP
30 AMP
ABCDEF6002-22 45 AMP 35 AMP
ABCDEF8002-22
60 AMP
45 AMP
ABCDEF10.2-22 80 AMP 60 AMP
Refer to local and national electrical codes for proper installation
guidelines. The breaker recommendations listed in the chart above are
intended for installations in North America. For international installations,
please refer to the local and national electrical codes and standards.
