Ametek Powervar Security Plus II User Manual

12
A01-00150 Rev B
4.2 Wiring Diagrams (Hardwired units only)
For North American applications, UPS models may be configured for
an input voltage of 208 or 240 volts at 60 Hz. SSO tap must match
customers expected line to line Output voltage. Output voltages for
these models are available at 120, 208 (using the 120 & 88 terminal
block position) and 240 volts at 60 Hz. See the table below to connect
terminal block in Figure 1 to achieve the desired input and output voltage
configurations.
NORTH AMERICAN CONNECTIONS
VOLTAGE
RATING
INPUT OUTPUT
VOLTAGE
L1 - L2 FREQ VOLTAGE
NEUTRAL
BOND FREQ
SSO TAP
JUMPER
208 208 60 120 10.0 88 0 120
SEE
DIAGRAM
60
208-(0)
240 240 60 120 8.0 88 0 120 60 240-(0)
NOTE:
The neutral to ground bond connection must be properly
connected for domestic or international configuration
For international applications, UPS models may be configured for an
input voltage of 220, 230 or 240 volts at 50 Hz. SSO tap must always be
set to 240. Output voltage for these models matches the input voltage at
50 Hz. See the table below to connect to the terminal block in Figure 2 to
achieve the desired input and output voltage configurations.
INTERNATIONAL CONNECTIONS
VOLTAGE
RATING
INPUT OUTPUT
VOLTAGE
L1 - L2 FREQ VOLTAGE
NEURTRAL
BOND FREQ
SSO TAP
JUMPER
220 220 50Hz 0 -- 110 220
SEE
DIAGRAM
50Hz 240-(0)
230 230 50Hz 0 -- 115 230 50Hz 240-(0)
240 240 50Hz 0 -- 120 240 50Hz 240-(0)
