Introduction
M370430-01 Rev F 1-7
1
Rear Panel Connectors on 850 Watt Models
Figure 1-3 XG 850 Watt Units: 6 V to 40 V Models
Figure 1-4 XG 850 Watt Units: 60 V to 150 V Models
Figure 1-5 XG 850 Watt Units: 300 V to 600 V Models
