M O D E L 2 1
O P E R A T
I O N M A N U A L
8
88
8
4.1 WELDHEAD USER INTERFACE
1. ON/O
FF – Used to power on/off the weld head independent of the interface box
when changing heads.
2. MODE – Used to toggle between Field Mode (F) and Bench Mode (B).
3. SET ALIGN – Used to set the alignment of the inserts, referencing one side to the
other. Ref Section 4.3.
4. CYCLE – Used to actuate the weld head clamping and begin the weld cycle
(same function as right foot pedal). Ref Section 4.4.
5. ABORT – Used to abort the weld cycle and open the clamping jaws (same
function as left foot pedal).
6. Home Position Locator – Used to set the rotor home position with a 1/16” pin.
Ref Section 6.3.
7. Green LED – Used to identify status situation.
8. Red LED – Used to identify alarm situations.
9. DISPLAY – Used to indicate mode, status, and alarms as shown in the “Display
Legend”. Ref Section 4.1.1.
4.1.1 DISPLAY LEGEND
DISPLAY LE
GENDDISPLAY LEGEND
DISPLAY LEGEND
Modes (green led)
SA = Set Alignment mode
F1 = Field Mode 1- no center pin, Cycle Abort to open
F2 = Field Mode 2 -center pin, Cycle Abort to open
B1 = Bench Mode 1-no center pin, Auto open
B2 = Bench Mode 2-center pin, Auto open
Status indicators (green led)
HP = Home Position – rotor is at home
AC = Auto Cooling – cooling cycle is in process
Alarms (flashing red led)
SS = Safety Switch – clamping motion is incomplete
CP = Center Pin – center pin has not completely protruded or retracted
HP = Home Position – rotor is not at home
