DESCRIPTION OF THE APPLIANCE
Description of KMC* induction hob
Touch control sensor panel
Rear left cooking zone
Ø 145
Double ring rear right cooking zone
Ø 170 x 265
Triple ring front left cooking zone
Ø 210/175/120
Double ring front right cooking zone
Ø 180/120
1. On/off sensor
2. Cooking zone selector sensor,
3. Cooking zone displays,
4. Heat setting selection sensor eld
5. Double and triple cooking zone selector
sensor eld
6. Double and triple ring LED pilot light
7. Child lock sensor with LED pilot light,
8. Timer sensor,
9. Timer display,
10. LED pilot light indicating timer operation
for a given cooking zone,
