3.1 De scrip tion
The APF 12/33 / 15/40 / 15/50 / 20/50 are for ward mov ing vi bra -
tory plates that uses a trac tion-os cil lat ing sys tem.
The en gine drives the vi bra tor via a cen trif u gal clutch and V-belt.
The ma chine is suit able for the com pac tion of sand, gravel (pos -
si bly coarse gravel), lean con crete, as phal tic bi tu men-coated
gravel (me dium and fine grained) and pav ing stones.
3.1.1 Equip ment over view
1 Base plate
2 Ex citer
3 Wa ter tank
1)
4 Cen tral-point sus pen sion
5 En gine
6 Drawbar
7 Bogie
1)
8 Cen trif u gal clutch
1)
Op ti on
74020000-2 HbmG gnu thci dreV nna mmA 7102/90
3. Ope ra ti on
Haz ard from ma chine slip ping.
• Be care ful on slopes! Slip ping haz ard from un -
coil ing ma te rial and slick sur faces.
• Do not drive on hard con crete, set bi tu men sur -
faces, or ground that is frozen solid or does not
have ad e quate load ca pac ity.
