4.1 Bogie
1)
Use the bogie en ables the vi bra tion plate to be eas ily trans ported
over short dis tances.
• Press towbar (1) down as far as the stop.
• Move lock ing pin (2) into open ing on the towbar.
• De tach bogie (3) from fix ture (4) and place on the ground.
• Tilt vi bra tion plate with towbar locked onto its front edge. The
bogie swings down be low the plate.
1)
Op tion
• Tilt vi bra tion plate back with the towbar un til the plate is po si -
tioned hor i zon tally on the bogie. The equip ment can now be
moved.
• Af ter trans port ing adopt the re verse pro ce dure and at tach
bogie.
