OPERATING MANUAL2.8 Machine transport
• The machine can move on its own within the work site.
When driving, observe the safety measures applicable to
the working site.
• The machine should be transported on avehicle on public
roads.
When transporting the machine on a vehicle, observe
regulations applicable to the given territory.
Use the loading mode to load the machine. Switch over the
travel mode selector (4) to position “0”.
When loading and unloading, the vehicle transporting
the machine must be braked and mechanically protected
against accidental movement using wedges (1).
The articulation joint of the machine must be secured
with astrut against tilting on the vehicle.
The machine on the vehicle must be properly anchored
and mechanically secured with the slings (2) in tie-down
holes against longitudinal and lateral displacement as
well as against overturning. The machine drums must be
secured against accidental movement using wedges (3).
If the machine is equipped with folding scrapers, the
scrapers must be folded, see Chapter 3.6.9 Scraper
adjustment.
Take extra care when loading a machine with a plastic
canopy.
