Ammann ARX 26-2 - Technical Data

14 ARX 23-2 T4i, ARX 26-2 T4i
ARX 23-2 ARX 23-2C ARX 26-2 ARX 26-2C
EU Stage IIIA / U.S. EPA Tier 4i
Weight
Operating weight of EN 500-1+A1
(CECE)
kg (lb) 2260 (4980) 2110 (4650) 2460 (5420) 2300 (5070)
Operating load of EN 500-1+A1
(CECE) on front axis
kg (lb) 1070 (2360) 1070 (2360) 1180 (2600) 1180 (2600)
Operating load of EN 500-1+A1
(CECE) on rear axis
kg (lb) 1190 (2620) 1040 (2290) 1280 (2820) 1120 (2470)
Weight of half uid capacities kg (lb) 110 (240) 115 (250) 110 (240) 115 (250)
Operating weight of ISO 6016 kg (lb) 2275 (5020) 2135 (4710) 2475 (5460) 2315 (5100)
Maximum weight with accessories kg (lb) 2495 (5500) 2310 (5090) 2655 (5850) 2500 (5510)
Maximum permitted weight accord-
ing to ROPS
kg (lb) 2850 (6280) 2850 (6280) 2850 (6280) 2850 (6280)
Static linear load of front drum kg/cm (lb/in) 10.7 (20) 10.7 (20) 9.8 (20) 9.8 (20)
Static linear load of rear drum kg/cm (lb/in) 10.9 (20) - 10.7 (20) -
Weight of Canopy kg (lb) 35 (80) 35 (80) 35 (80) 35 (80)
Weight of Ammann edge cutter kg (lb) 50 (110) 50 (110) 50 (110) 50 (110)
Deduction for the transport weight
to the EN 500-1+A1 (CECE) operat-
ing weight.
kg (lb) 180 (400) 185 (410) 180 (400) 185 (410)
Driving characteristics
Maximum transport speed km/h (MPH) 11 (6.8) 11 (6.8) 11 (6.8) 11 (6.8)
Climbing ability without vibration % 35 35 35 35
Climbing ability with vibration % 30 35 30 35
Lateral static stability % 55 46 62 53
Lateral stability during driving with-
out vibration
% 25 20 25 20
Lateral stability during driving with
vibration
% 15 10 15 10
Turning radius inner (edge) mm (in) 2630 (103.5) 2630 (103.5)
2540 (100) 2540 (100)
Turning radius outer (contour) mm (in) 3750 (147.6) 3750 (147.6) 3910 (153.9) 3910 (153.9)
Type of drive - Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Number of driving axles - 2 2 2 2
Oscillation angle ° 6.5 6.5 6.5 6.5
Angle of steering ° 30 30 30 30
Steering
Type of steering - Joint Joint Joint Joint
Steering control - Hydraulic Hydraulic Hydraulic Hydraulic
Linear hydraulic motors - 1 2 1 1
1.3 Technical data
