145ARX 23-2 T4i, ARX 26-2 T4i

615111A

611303

615052A

MAINTENANCE MANUAL

3.6.25 Sprinkling lter cleaning

Remove the sprinkling lter vessel, remove the sieve, clean it

and mount back.

Check the seal.

Replace if damaged.

Remove and clean the sprinkler strainers.
