67ARX 23-2 T4i, ARX 26-2 T4i
OPERATING MANUAL
Selection of the travel direction
• Selection of the travel direction is set on the active travel control. Set and leave the inactive travel control in the parking brake
position (P).
• Move the travel control (11) from the parking brake (P) to the neutral position (N) – releasing of the brakes, the parking brake indi-
cator lamp (29) goes out.
• Move the travel control (11) to the position (0) and select a travel direction (F/R).
When the driver releases the travel control (11), it does not return to the zero position automatically. The travel control remains in the
selected position.
When the driver quickly moves the travel control (11) through the zero position (0) from the selected direction of the machine travel,
e.g. due to a dangerous situation, the machine stops and the parking brake is engaged (panic response).
When the driver moves travel control (11) from the selected direction of machine travel to the neutral position, e.g. due
to a dangerous situation, the machine stops but the parking brake is not engaged. This may cause counting movement
of the machine when driving down the slope, due to leakages form the hydraulic system.
Travel speed selection
• The travel speed is set on the active travel control. Set and leave the inactive travel control in the parking brake position (P).
• The travel speed corresponds to the deection of the travel control (11) from the zero position (0) at the given engine speed (3)
and mode of operation (4) of the machine.
• The travel speed can be changed with the travel mode switch (4).
Panic response
The immediate stop of the machine using the travel control (11) applies to all of the travel modes of the machine. When the travel
control (11) is changed to the opposite position through (0) within 1 second, the machine will stop – the parking brake will be engaged
and the engine will keep running, i.e. panic response. When the machine vibration is on, the vibration will stop also when the manual
vibration mode is selected. When the machine is equipped with two travel controls, the panic response can be enabled also on the
inactive travel control. The machine can start moving again after the travel control (11) is changed to the neutral position (0) and the
travel direction (F/R) is selected.
Note
If the driver leaves the driver’s seat while the travel control is not in the brake position (P), the machine behaves according to the seat
switch description (Chapter 2.6).
When the driver moves travel control from the brake position (P) without sitting on the seat at that time, the engine will be stopped
after 5 seconds.
