Maintenance
Revision: 7 – Mar 2014 OMMB00010
Part
Number
Description
Qty
1096X(°F)
Element assembly
See table
2
1096P(°F)
Plated element assembly
2433X(°F)
Element assembly with manual override
2433P(°F)
Plated element assembly with manual override
5566X(°F)
Element assembly, higher over-temperature
7406X(°F)
Element assembly, higher over-temperature with manual override
6836S(°F)
Element assembly, ‘Saltwater’ plated
6938S(°F)
Element assembly, ‘Saltwater’ plated, with manual override
Table 6 – Element assembly part numbers
Seal Kits
Size
Material
BO/BC/BF/BH
BR
Nitrile
Viton
Neoprene
Nitrile
Viton
Neoprene
1.1/2”
46342X151
46342X152
46342X153
46342X154
46342X155
46342X156
2”
46342X201
46342X202
46342X203
46342X204
46342X205
46342X206
2.1/2”
46342X251
46342X252
46342X253
46342X254
46342X255
46342X256
3”
3BO,3BR
46342X301
46342X302
46342X303
46342X304
46342X305
46342X306
3”
33BO, 33BR
46342X331
46342X332
46342X333
46342X334
46342X335
46342X336
4”
4BOA,4BOB
4BOC,4BOD
46342X401
46342X402
46342X403
46342X404
46342X405
46342X406
4”
4BOR,4BOS
4BRR,4BRS
46342X411
46342X412
46342X413
46342X414
46342X415
46342X416
5”
46342X501
46342X502
46342X503
46342X504
46342X505
46342X506
6”
46342X601
46342X602
46342X603
46342X604
46342X605
46342X606
8”
46342X801
46342X802
46342X803
46342X804
46342X805
46342X806
Table 7 – Seal kit part numbers
Please note that 4” and 5” B valves as of 2010 and 6” and 8” B Valves
as of 2011 now use ‘O’ rings to seal the upper and lower housing. The
seal kits for these valves contain the original type gasket and the ‘O’
rings to suit both types of sealing configuration.
